Electric Forklift 4500 MM
Rs.1,425,000.00
Electric forklift with a 3,000 kg load capacity and 4.5 m (4500 mm) 3-stage mast. Designed for heavy-duty material handling, featuring solid tires, DC drive motor, hydraulic steering, and advanced safety systems — ideal for warehouses, factories, and logistics.
This high-performance Electric Forklift offers a 3000 kg rated load with a 4500 mm lift height via a 3-stage mast, making it suitable for high stacking and versatile indoor/outdoor use. The wide-view mast design improves visibility and safety, while the DC drive motor delivers smooth acceleration, low noise, and zero emissions — perfect for warehouses, manufacturing plants, and food or pharmaceutical facilities.
The unit comes equipped with a 60V 130Ah lead-acid battery, multi-function LED dashboard with battery discharge indicator and fault codes, overload alarm, hydraulic service brakes, and mechanical parking brake. Solid tires, a heavy-duty axle, and a steel counterweight ensure stability and durability in demanding environments. Easy to operate and maintain, this forklift is built to enhance productivity and reduce operating costs.
Specifications:
| Specification | Details |
|---|---|
| Brand | Rudra Equipment |
| Product Name | Electric Forklift |
| Series | CPD45 |
| Model | FBLB30S (4500 MM / 3-Stage Mast) |
| Model No. | FBLB30S |
| Power Type | Electric |
| Load Capacity | 3000 kg |
| Overall Size Less Forks (L × W × H) | 2590 × 1110 × 2180 mm |
| Load Centre | 500 mm |
| Lowered Height | 2100 mm |
| Lift Height & Stage | 4500 mm, 3-Stage |
| Front Overhang | 420 mm |
| Rear Overhang | 360 mm |
| Wheel Base | 1780 mm |
| Minimum Ground Clearance | 100 mm |
| Wheel Track F/R | 970 / 935 mm |
| Turning Radius I/O | 520 / 2580 mm |
| Tilt Angle F/R | 6° / 6° |
| Fork Size (L × T × W) | 1070 × 40 × 120 mm |
| Travel Speed Load/Unload | 13 / 16 km/h |
| Maximum Gradeability Load/Unload | 15 / 20% |
| Number of Wheels / Drive Wheel | 4 / 2 |
| Tire Type | Solid |
| Tire Size F/R | 6.50-10 / 5.00-8 |
| Service Brake | Hydraulic |
| Parking Brake | Mechanical |
| Controller | HaiQing |
| Battery Voltage / Capacity | 60V / 350Ah |
| Battery Type | Lithium Battery |
| Motor | 4 kW |
| AC Drive Motor | 5 / 7.5 kW |
| AC Oil Pump Motor | 4 kW |
| Weight | 3360 kg |
| Rated Loading | 3000 kg |
| Loading Centre | 500 mm |
| Free Lift Height | 1544 mm |
| Lift Speed No Load | 204 mm/s |
| Lift Speed Full Load | 180 mm/s |
| Front Axle Load No Load | 1510 kg |
| Front Axle Load Full Load | 5530 kg |
| Rear Axle Load No Load | 1750 kg |
| Rear Axle Load Full Load | 430 kg |
| Travel Speed No Load | 16 km/h |
| Travel Speed Full Load | 13 km/h |
| Gradeability | ≤15% |
| Minimum Turning Radius | 520 mm |
| Length with Fork | 3660 mm |
| Width | 1110 mm |
| Height Without Overhead Guard | 985 mm |
| Height with Overhead Guard | 2170 mm |
| Maximum Working Height | 5550 mm |
